What makes CNC machines so unique and widely popular?
Small size 6090 machine suitable for homework, easy to operate, accuracy is high, can process artwork, soft metal, metal and woodworking jobs.
Cheap CNC milling router machine with good price and good performance.
CNC Router Milling Cutting on Aluminum Machine Specification:
#Working area: 600*900*150mm
#Spindle:China 5.5kw water cooling spindle
#Control system:DSP A11 control system
#Drive system:China stepper motors and drivers
#Transmission:XYZ by helical gear, Z by Taiwan TBI ball screw
#Table:T-solt table Moving
#Fuling Inverter
#Tool sensor
#Tools box (including all tools for machine)
| Parameters | JNM6090 CNC Milling Machine |
| Working Area | X*Y*Z:600mm*900mm*150mm |
| Control system | DSP A11 Control system |
| Inverter | Fuling inverter |
| Spindle | 5.5kw water cooling spindle,24000RPM |
| Motor | Stepper motor and drivers system |
| Transmission | X Y Gear tranmission |
| Machine bed structure | T solt moving table |
| ATC | Not |
| Electrical device | French Schneider |
| Cutting speed | 0-35m/min(depending on material and thickness) |
| Positioning accuracy | ±0.02mm |
| Repositioning accuracy | ±0.02mm |
| Eauipment power | 10KW |
| Calibration | Tool sensor |
| Command Language | G code |
| Power supply | 380V/3P/50?60?HZ?220V/3P/50?60?HZ? |
| Interface | USB |
| Software | Artcam/Ucancam/Aspire/Alphacam/Fusion 360/UG etc. |
| Running Environment | Temperature: -10?~45? |
