#Pre-milling:Mill the glued surface again to make it smoother and enhance adhesion. The plate processed by the normal engraving machine cutting machine is smooth enough.
#Gluing :Adopt advanced down-setting glue case,high speed glue heating;double spiral feeding structure,ensure its stability and glue evenly.
#End Cutting :By precise linear guide motion,adopt explorator automatic Tracking and high frequency,high speed motor high speed cutting and other structure, ensure the cutting surface flat and smooth.
#Fine Trimming:The device is used for trimming extra edge banding material from upper and under of edgeband for processing board;adopt explorator automatic tracking and high frequency,high speed motor and other structure,ensure upper and under of board is flat and smooth when edging.
#Corner Triming:The corners can be rounded up and down, and the four
corners can be rounded to make the end of the sheet more smooth and round.
#Straight Scraping:The device is used for removing corrugated trace due to the trim of linear motion by the cutting process to make the upper and under of sapwood more smooth and clean.
#Buffing: The device is used for cleaning processed board by cotton buffing wheel,ensure edging side is more smooth.
Parameters of 8 Functions Automatic Edge Banding Machine
|
Model |
JNF508 Edge Banding Machine |
|
Motor power |
14.8kw |
|
Size |
6000×900×1600mm |
|
Feed speed |
12m/min |
|
Panel thickness |
10-60mm |
|
Edge thickness |
0.4-3mm |
|
Panel width |
≥ 80 |
|
Weight |
2000kg |
|
Working airpressure |
0.6Mpa |
What Can 8 Functions Automatic Edge Banding Machine/CNC Edge Banding Machines Do?
Automatic edge banding machines are used to pre-mill, bond the edge banner to the substrate, trim the leading and trailing edges, trim top and bottom flush with the substrate, scrape any surplus, and buff the finished edge. All works will be finished in one machine, which is an upgraded version of the traditional manual edge banding in modern furniture making.
Features of 8 Functions Automatic Edge Banding Machine
1. Panel type: MDF, blockboard, solid wood board, particle board, polymer door panel, plywood and other types of man-made panels, widely used in panel furniture, cabinets and other furniture industries.
2. Protect the board: Adhesive is also needed between the edge banding and the furniture board. This method of reinforcement from the side makes the board difficult to be glued and cracked.
3. Aesthetic and decorative effect: use different color boards with different color edge banding, the beautiful and generous edge banding is delicate, smooth, and feels good, and the sealing line is straight and smooth.
