What makes CNC machines so unique and widely used in a broad range of industries?
CNC Router machines simplify aluminum machining, it doesn’t mean fabricating aluminum parts is any less complex than it used to be. There are many aluminum grades (or alloys) available in the market today, and the success of your project will depend on you choosing the most suitable aluminum alloy and Aluminum CNC milling machine for your project.
Why Aluminum and Aluminum Milling machine is popular?
Good Machinability: Aluminum is easier to machine than many other metals. It chips easily, making it easy for CNC machine operators to create complex parts quickly and accurately.
High corrosion resistance: Aluminum develops a thin hard film of oxide (aluminum oxide) when exposed to air or other oxidizing agents. This oxide makes aluminum corrosion-resistant and prevents chemical damage.
High strength-to-weight ratio: Given its high strength, aluminum is remarkably light. As such, you can make aluminum parts thicker and stronger while still reducing weight in applications that require lightweight materials.
Recyclability: Aluminum has high recyclability, making it perfect for businesses looking to mitigate the material wastage challenge of CNC machining.
Custom Finishing: Aluminum offers a wide range of surface finishing options, including anodizing and painting, to give your parts the perfect custom look
CNC Router Milling Cutting on Aluminum Machine Specification:
#Working area: 2000*3000mm*200mm
#Spindle:Italy HSD 9kw air cooking HSK63 high power for cutting aluminum,24000RPM
#Control system: Syntec 60WE Control system with handle wheel control
#Japan Yaskawa 850w servo motor and drivers system
#Transmission:XYZ by Taiwan 40mm TBI ball screw
#Rail guide: Taiwan T-Win30mm linear square rail guide
#Table: vacuum working table+T-solt table
#Safety security barriers one set (6pcs)
#Inverter: Delta inverter
#12 pcs carsouel tool change(Following gantry)
#Mist cooling system for aluminum
#French Schneider electronic parts
#5.5kw dust collector with two bags,new design type
#2 sets 7.5kw air vacuum pump
#Automatic Z setting with auto Tool sensor new model 1pcs
Parameters : JNM2030C CNC Router Milling Cutting on Aluminum machine Standard Specifications
Working Area: X*Y*Z: 2000mm*3000mm*200mm
Control system: Taiwan Syntec 60W-E Control system
Inverter: Taiwan Delta inverter
Spindle: 9.0kw HSD air cooling ATC spindle,24000RPM
Motor: Yaskawa servo motor and drivers system
Transmission: X Y Z axis 40mm Ball screw tranmission
Machine bed structure: T solt or T solt +Vacuum table
ATC: Yes,Follow Gantry carsouel tool change,
Cutting speed: 0-35m/min(depending on material and thickness)
Positioning accuracy: ±0.02mm
Repositioning accuracy: ±0.02mm
Eauipment power: 20KW
Software : Artcam/Ucancam/Aspire/Alphacam/Fusion 360/UG etc.
